    • Disintegration Tester - DT -101

    Product Image

    Disintegration Tester - DT -101

    The DT-101 Disintegration Tester is a solid-state pharmaceutical testing instrument designed to accurately measure the disintegration time of tablets according to IP and USP standards. Engineered with a dual-basket system and high-resolution touchscreen interface, it allows testing of two batches (6 tablets each) simultaneously. With precision temperature control, memory storage, and robust construction, it is ideal for pharmaceutical labs and quality control departments.

    Download PDF

     Key Features:

    Dual-basket assembly to test 12 tablets at once

    High torque AC motor for stable performance

    Acrylic water bath with easy-clean design

    Integrated cartridge heater with quick connector

    Real-time temperature monitoring via sensors

    Built-in memory for storing batch and product data

    Complies strictly with IP and USP standards

    Audio-visual indicators for operational feedback

    Highly accurate and user-friendly operation



    SPECIFICATIONS :

    ParameterSpecification
    Display5" High-Resolution Touch Screen Display
    Basket2 x 6 Test Positions (10 mesh), USP Type A
    Beaker Volume1000 ml
    Dip Speed30 ± 1 DPM
    Stroke Length55 ± 1 mm
    Test Disk6 Numbers in each basket (USP Type A)
    Water Bath Temperature RangeAmbient +5°C to 40°C
    Temperature Accuracy±0.3°C
    Data Storage100 Test Results
    Password Protection3 Level Password
    Users1 Admin and 10 Users
    Resolution0.1°C
    Water Bath CirculationHigh Quality Magnetic Pump
    Heater400W Inbuilt (No heater method at rear side)
    Test ModeMultiple programmable test modes (99:59:59 Max)
    PrinterSerial Port
    PC ConnectivityYes
    Environmental Conditions20-40°C, ≤80% RH, Non-condensing
    Dimensions (L x B x H)420 x 380 x 520 mm
    Weight18 kg
    Power Supply230V ±10% / 50-60 Hz or 115V ±10% / 50-60 Hz
